Product Description:
The Sandwich Panel Roll Forming Machine is designed to meet the
high performance requirements. It adopts the PLC control system,
transmission with gear/sprocket, and has a high precision cutting
length. This Sandwich Panel Forming Machine is ideal for producing sandwich panels with
high accuracy, high efficiency and stable performance. With a wide
range of applications, it is an ideal choice for sandwich panel
forming operation. Its advanced technology ensures a reliable,
efficient and safe operation in various environments.
Features:
- Product Name: Roof Panel Roll Forming Machine for YX1000 Sandwich Panel Profile
- Roller Station: 11 Stations
- Material: PPGI
- Transmission: Gear/sprocket
- Forming Speed: 15m/min
- Drive Type: Motor Driving
- Sandwich Panel Roll Forming Machine
Drawing:
Technical Parameters:
| Roll Forming Machine For Sandwich Panel YX1000 Profile |
|
| Material Specification |
| Thickness | 0.35mm to 0.7mm |
| Effective width | 1000mm |
| Feeding width | Approx.1077mm |
| Material | PPGI |
| Yield strength | 250MPa |
|
| Roll Forming Machine |
| Driving system | Gear/sprocket |
| Forming station | 11 stations |
| Roller material | 45# steel, CNC lathes, hard chrome coated |
| Option for roller material | Cr12, Cr12Mov |
| Shafts Diameter | Φ75mm |
| Main motor | 5.5KW, frequency speed control |
| Line speed of rollformer | Approx. 15m/min |
|
| Hydraulic Cutting Device |
| Cutting type | Slug breaker |
| Cutting tool material | Cr12, heat treatment |
| Hydraulci pump motor | 4KW |
|
| PLC Control System |
| Function | Control quantity and cutting length automatically |
| PLC | Siemens |
| Touch screen | Siemens |
| Inverter | Schneider or Delta |
| Encoder | Omron |
| Cut-to-length tolerance | ≤±2 mm |
| Control Voltage | 24V |
|
| Product Rack | 4 meters×3 |
Applications:
XIAMEN FUMING Sandwich Panel Roll Forming Machine, model number
YX1000, is a reliable and cost-effective equipment. The voltage of
the equipment can be customized.
Support and Services:
Sandwich Panel Roll Forming Machine Technical Support and Services
We provide comprehensive support for Sandwich Panel Roll Forming
Machines, including:
- Remote technical support
- On-site maintenance and repair services
- Training and consultation to ensure optimal operation
- Warranty service
Our team of experienced professionals will work with you to ensure
your Sandwich Panel Roll Forming Machine is running efficiently and
reliably.
If you have any questions or require support for your Sandwich
Panel Roll Forming Machine, please contact us.
FAQ:
Q 1: How can customers be assured that XIAMEN FUMING will deliver
qualified roll forming machines?
A 1: Customers can send their technician or entrust a third party
to XIAMEN FUMING’s factory to do machine inspection before
delivery.
XIAMEN FUMING can send their engineers to the buyer’s factory for
machine installation and commissioning.
Our roll forming machine is guaranteed for one year in correct
operation and maintenance.
Q 2: How does the customer install the machine when it arrives?
A 2: Our engineers will go to your factory for machine installation
and commissioning once you get your machine ready(including
electricity, testing material, hydraulic oil, auxiliary staff,
transport and lifting device, etc.), they will instruct your
technician how to operate the machine. Online supports including
video call will be provided if our engineers cannot visit your
place because of pandemic.
Q 3: Does XIAMEN FUMING provide customized roll forming machines?
A 3: Yes, we design and make roll forming machines according to the
latest market trend and the specific requirements suggested by
customers.
